Joint CSS and SVG Meeting


CSS Stroke and Fill Specification

The CSS working group would like to allow the use of the SVG ‘stroke’ and ‘fill’ properties on CSS text as well as other places in CSS (e.g. box border). They’ve created a prototype document that basically copies the SVG stroke and fill text adding the necessary parts to get it to work with CSS text. This document has been temporary called Text Decoration 4 (the title will certainly be changed). They’ve proposed converting the ‘stroke’ and ‘fill’ properties to short-hands. (A short-hand property allows setting multiple CSS properties at the same time.) They also would like to see the ‘stroke-alignment’ property implemented (this property allows one to stroke only the inside or only the outside of a shape). I pointed out the difficulty in actually defining how ‘stroke-alignment’ would work. The SVG WG moved some of the advance stroking properties out of the SVG 2 specification into an SVG Stroke module to avoid holding up the SVG 2 specification. (See my blog entry on this as well as the issues in the SVG Stroke module.) Other issues discussed were how glyphs are painted (‘paint-order’, ‘text-shadow’), multiple strokes/fills, dashing, and ‘text-decoration-fill/stroke’.

Text Issues

Next we covered a whole slew of text issues I raised dealing with flowed text in SVG.

Strategy for using CSS in SVG for wrapping

The first issue was to agree on how SVG and CSS are related. I presented my strategy: that HTML/CSS and SVG have there own methods to define an area to fill called the wrapping area. Once this area is defined, one uses CSS rules to fill it. Here is how one defines the wrapping area in both HTML/CSS and SVG:

The CSS/HTML code:
      .wrapper { shape-inside: xxx; ... }
      .float-left { shape-outside: yyy; ... }
      .float-right { shape-outside: zzz; ... }
    <div id="wrapper">
      <div id="float-left"/>
      <div id="float-right"/>
	Some text.
The result:
Defining a fill area using <div&gt and floats.

Wrapped text in HTML. One starts with a wrapper <div>. The ‘shape-inside’ property on this <div> reduces the wrapping area to the circle. Two floats <div>s are defined, one on the left (green rectangle) and right (red rectangle). The area that the floats exclude is reduced by the half-ellipses defined by the ‘shape-outside’ property. The final wrapping area is the light blue shape.

The CSS/SVG code:
      .my_text { shape-inside: xxx; shape-outside: yyy, zzz; ... }
    <text id="my_text">Some text.</text>
The result:
Defining a fill area in SVG.

Wrapped text in SVG 2. One starts with a element. The ‘shape-inside’ property on this element defines the wrapping area. The ‘shape-outside’ property reduces the wrapping area. The final wrapping area is the light blue shape.

It was pointed out at a discussion on Day 2, that the use of ‘shape-outside’ in SVG was not consistent with the CSS model. The ‘shape-outside’ property defines the effective shape of an element as seen by other elements. We agreed to change ‘shape-outside’ to an SVG only property ‘shape-subtract’.

How is the first line placed in a wrapped shape?

When the top of a wrapping area is not horizontal, how do you decide where the first line of text is placed?
Different strategies for locating the position of the first line in pyramid shape.

Alternative solutions for where to start layout of the first line, from top to bottom: First place a chunk of text fits: No restrictions, Restricted to multiples of ‘line-height’, Restricted to multiples of half ‘line-height’.

We were informed that with CSS floats, the line is moved down until the first text chunk fits. To be consistent with CSS, we should follow the same rule. A future CSS Line Grid specification may allow one to control line position.

Overflow text

What should happen when the shape isn’t big enough for all the text? This is mostly an issue for browsers where the user can specify a larger font (i.e. for accessibility reasons). CSS has an ‘overflow’ property that selects either clipping or scrolling. Neither of these is a great solution for SVG. The tentative solution in the CSS Shapes 2 specification of extending the <div> below the wrapping area doesn’t work for SVG. I proposed that there should be a means to expose the overflowed text, such as displaying it on hovering over the ellipses at the end of the displayed text. There was some interest in this. For the moment, the best solution is probably to explicitly not define what should happen, leaving it to a future time to specify the behavior. In reflecting on this after the meeting, I think one strategy is to suggest that authors provide an overflow region by adding an additional shape to the value of the ‘shape-inside’ property.

How does text wrap in a shape with a doughnut hole or other feature that breaks a line into parts?

Since SVG can have arbitrary shapes, it is possible to create shapes that break a single text line into parts. How should these shapes be filled?
A shape a bit like an 'H' showing text be laid out on both sides of the central break.

An example of a shape that breaks lines into parts.

The ‘wrap-flow’ property does not apply here as that dictates how text is flowed around floats. A new ‘wrap-inside’ property has been proposed. For the moment, however, it was agreed that text should flow as shown in the above figure. This would be the default value of any new property.

Flowing into multiple shapes

The aborted SVG 1.2 specification allowed text to be flowed sequentially into multiple shapes. This is something that Inkscape implemented and I would like to see this ability preserved. The proposed CSS methods for doing this don’t work for SVG. I proposed giving the ‘shape-inside’ property a list of shapes. It was agreed that this would be an acceptable solution for SVG. (And it can provide a place for over-flowed text.)

How is the first glyph positioned on a line?

When dealing with rectangles, it is straight forward to find the position of the first glyph but with arbitrary shapes it is more difficult. I asked what was the correct CSS method. I was told that one considers the glyph box extended upwards/downwards as dictated by using the height of the entire line box. (For example, if one has a ‘line-height’ value of 2 with a 16px font, the line box has a height of 32px.) It’s not clear where this is specified in CSS.

Baseline issues

We next switch from text wrapping to baseline issues. Text is normally laid out along a baseline which can be different depending on the script. For example, western scripts normally use an Alphabetic baseline while Indic scripts use a Hanging baseline.
Three different scripts showing their baselines.

Example baselines (red lines) in three different scripts. From left to right: alphabetic, hanging, ideographic. The EM box is shown in blue for the ideographic script.

The proposed CSS definition of the ‘dominant-baseline’ property differs from the SVG 1.1 definition in that several of the SVG 1.1 values are missing. We discussed the missing values. Some of the missing values will be added to the CSS definition. There is one fundamental difference between CSS and SVG 1.1: With SVG 1.1 (and XSL 1.1), the baseline table does not change automatically when the font size is change. One must explicitly reset the table by setting the ‘dominant-baseline’ property to the ‘reset-size’ value. The proposed CSS definition will automatically reset the table on change in font size. I’m not sure this is a necessarily good change (it’s definitely not backwards compatible) but then this is probably such a small corner case that it doesn’t really matter.

Figure from the XSL 1.1 specification showing the default behavior upon ‘font-size’ change. The baseline table does not change.

The CSS ‘auto’ value has one small problem for SVG. With vertical text, if the value of ‘text-orientation’ is ‘sideways’, the alphabetic baseline is used. SVG 1.1 always uses the central baseline for vertical text. The CSS specification will be fixed to be compatible with SVG 1.1.

We also discussed default values for the various baselines. In principle, one gets the values of the baselines from the font but most fonts don’t have baseline tables; for interoperability we need defaults. It was decided that the CSS group would investigate this more and come up with a recommended set of default values.


I brought up a couple of issues dealing with SVG/CSS Filter Effects module. The first was the status of the document. Progress towards finishing this document seems to have stopped. Two of the three editors are no longer very active. The third editor was present and said he would push this through.

I was also interested in the next level as I have a filter primitive I would like to see added. It turns out that Level 2 has already been started. Not much is in there now. Apple, however, has a bunch of filter primitives they would like to add.

Next we covered the issue of artifacts created by using eight bit per channel colors (8 bpc) in the filter chain. The specification as written doesn’t directly specify that 8 bpc color should be used but a couple examples do assume this. I proposed that they be converted to use the range 0 to 1 so that one can use floats to describe color channels. This would solve the problem. Dean Jackson from Apple will investigate the possibility of requiring that floats be used rather than ints in the filter chain.

A blob showing artifacts due to the use of only an 8 bit bump map as input to a lighting filter primitive.

An example of the artifacts one gets due to using only 8 bit alpha channel bump map as the input into a lighting filter primitive.

Gradient Banding

An unplanned topic… how to get rid of banding in gradients. Dithering is a well known technique. Can dithering be added to CSS gradients? There seems to be support for this idea. The syntax and technique needs to be specified.

SVG Meeting — Day 1
